Single-Rope Mechanical Orange Peel Grab

Single-Rope Mechanical Orange Peel Grab
Single-Rope Mechanical Orange Peel Grab Quality Advantage

Description:

Qinfan Company provides wide solutions for any bulk material that can be used on all hoisting equipment in China. You can choose from a range of motor-hydraulically, mechanically, and electro-hydraulically operated grabs. This type of single rope mechanical grabs feature simple structure, easy operation, and low maintenance. Lifting capacities range from 5 to 30ton.

Application:

Now the cactus grabs are widely used in ports, vessel, mine, metallurgy, dump, and are exported in batches.

Features of Cactus Grab:

1. Easy to operate
2. High handling effect
3. Simple maintenance
4. Competitive price
5. Decreased cycle time thereby reducing operational cost
6. Noiseless and smooth operation

Single Rope Mechanical Grab:

Parameter of Cactus Grab:

SWL (t) 5 6 8 10 12 15 20 25 30
Grab Volume (300 Dome) (m3) 0.95 1.15 1.6 2 2.5 3.5 4.4 5.5 6.5
Sheave Diameter Æ (mm) 400 400 450 500 500 560 650 560 650
Specs Diameter of Steel Rope Æ (mm) 17.5 19.5 21.5 24 26 28 30 28 30
Parameter (mm) A 3420 3780 4120 4448 4850 5550 5830 6170 6570
B 2620 2790 3020 3240 3550 4050 4330 4570 4870
C 2080 2250 2420 2620 2880 2900 3300 3500 3680
D 2700 2990 3240 3470 3740 4200 4500 4800 5050
Dead Weight (t) 2.5 3 3.8 4.6 5.3 6.8 8.5 10.5 12.8
Operating Height (m) 7.5 9 9.5 10 10.5 11 12.8 13.5 14
Remark








Note: we can customize as per client’s requirements.
